Working Principles:

Designed to refine and press the soap flakes from vacuum dryer, increase the density and transparency of soap, and then knife equipped at the pelletizing mouth would cut soap flakes into soap noodles.

Its working principle is to use the transmission of the spiral blade to make the soap flakes fully contact and squeeze inside the cylinder wall. The rotating screw blade, its own weight and the friction between the shell make the soap flakes moving forward and transporting to the muzzle, then soap flakes are cut into granules by the orifice scraper on the nose to become soap noodles (semi-finished products).


Technical Parameters:

Product name pelletizer/granulator/soap noodle making machine
ModelXT-1500
Materialcarbon steel A3
Capacity1000~2000kg/h
Power18.5kw
Screw diameter230mm*2
Screw typedouble screw
