Highly automatic Soap making machine Double Layer Duplex Screw Vacuum Soap Plodder 2500Kg per hour

The above and below screws and two orifice plates refine and compress the soap material to make the soap bar tight and have a bright surface. The below screw'speed can be adjusted to regulate the production capacity.

Click inquiry

Working Principle:

Vacuum plodder as the most important machine in the soap production line. A vacuum plodder grinding, refining,pressing soap noodles and other additives to obtain soap bar.

After mixing and refining soap noodles and other additivies from our first layer two screws and then the second layer two screws. Where in the vacuum space extruded the bar soap which smooth and fine,not easy breaken.And use different shape extrude mouth can make different shape soaps.

Technical Parameters:

Product name	bar soap vacuum plodder/extruder
Model	XT-2500
Material	parts that touch with soap material all made of stainless steel 304
Capacity	2000~3000kg/h
Power	above:22kw below:30kw
Screw diameter	250mm*2
Screw type	double layer twin screw
